Scanvogn – Office Trailer 420 (4.2 x 2.28 x 2.9 m)
Office Trailer 420
A flexible office
The office cabin is one of our most popular models and stands on many construction sites throughout Scandinavia. It is possible to upgrade the cabin with mini kitchen, utility room and extra shelves. All Scanvogn cabins are customisable so if the standard solution is not quite what you need, you can make your portable bathroom exactly the way you want it. There is a range of additional options that can be included.
The 420 is the medium sized unit. Bigger than the 320 and smaller than the 570.
Options include a rear desk (across the back wall), a toolroom, kitchenette, air conditioning, and a battery and solar system.
Toilet Type
This model comes equipped with our standard flushing toilet waste disposal. For people who have a connection to external water and drainage on site, then this is the toilet solution for you. The toilet works like a normal toilet in the home (but with disposal for extra reliability) and therefore feels natural and comfortable. We supply the toilet in an upright or wall-mounted version, and with or without visible pipes. If the pipes are hidden, the cabin is built with a technical compartment, for easy servicing of the toilet. You can choose to change the toilet type to any of our 4 toilet types including Vacuum and combustion. Or you can choose to have your portable office without a toilet for additional space.
- With macerator toilet (direct sewer connect)
- With tank toilet
- With Jets Vacuum toilet
- With incinerator toilet
- With no toilet
Easy to use and clean
The trailer is connected to a standard tow-bar and can be set up and ready in a few minutes. This makes it possible to move the unit from place to place quickly and efficiently without any hassle. The cabin is made of clean and durable materials, saving time for cleaning and maintenance.
Ideal For
Scanvogn portable office trailers are ideal for a range of industries and applications such as:
- Music Festivals
- Catering & Hospitality Events
- Field Day Events
- Glamping Grounds
- Horse & Country Events
- Motor Racing
- Construction & Demolition Sites
- Exhibitions & Shows
- Outdoor Events
- Private Functions
- Sporting Events
The trailers provide clean and hygienic office facilities for staff.
Check out more information on the manufacturers website.
• AL-KO CHASSIS – Using German AL-KO parts on all standardised chassis to ensure you one of the best trailer systems on the market. Rubber torsion-independent suspensions make a smoother ride with maximum protection of goods being carried.
• VISABILITY – All external vehicle lights are high and low, high-quality LED sealed for high visibility whilst travelling.
• BEST PROTECTION – Galvanising is carried out after the chassis has been mechanically machined so that all edges and bolt holes are also protected.
• FULLY MOLDED CURVED ROOF – Molded roof with a smooth curvature to optimise strength and direct water/snow and dirt away from the centre of the roof to the gutter -front and rear.
• GUTTER SYSTEM – Directional gutters along the sides to gutter at each gable to direct water and dirt away from users, doors and windows.
• DURABLE PANELS – Using UV-stabilised bright white fibreglass which contains a high number of fibres for best strength and durability. Totally weatherproofed and the perfect base for vinyl wrapping.
• EU – CERTIFIED – All our standard windows are gas-filled double glazing for extreme thermal efficiency, and screen boxes and lights are EC certified. Our wagons can therefore be driven legally throughout the EU and Au, in extreme heat and cold.
• STRONG WALLS – All external walls are seam cut and placed so that the angles close tightly around the floor for maximum strength and tightness.
• ENERGY-FRIENDLY LIGHT – Using daylight white LED light strips in all rooms, which gives you a comfortable white and energy-friendly light with a modern look.
• SPECIAL COMPONENTS – We produce several of our own sub-components ourselves, so we can offer you higher quality at a reasonable price.
• GUARANTEED SPARE PARTS – We have a large spare parts warehouse, where most parts can be shipped from day to day.
• COMPACT LAMINATE – All our table tops are high-density compact laminate which will not rot or create mould. This makes them resistant to water and humidity & bacteria. Excellent for testing or catering rooms.
• TOUCH-FREE FITTINGS – Option to choose touch-free fittings or toilet flush. (Specific to Covid-19 compliance) With durable/fully washable materials, so you spend as little time on cleaning and maintenance as possible.
• SPACIOUS – With ceiling heights of 2100mm and bigger and widths from up to 2380mm, we pride ourselves on having the most spacious models.
• TOWABILITY – Our trailer systems use lightweight low-tare strong chassis, combined with very lightweight panels, we know we have the lightest, most efficient mobile room system available. Overrun mechanical all-wheel drum braked, with breakaway safety cables and independent handbrake – there is no adjustment needed by the user.
• ROI – All in all, with great resale values, this gives you the best business investment, easiest to manage, most sustainable fuel-saving mobile trailer system, on the market.
More Information
| Manufacturer | Scanvogn |
|---|---|
| Model Name | 6 Person Office With Water Flushing Toilet |
| Model Number | 1800022/1850022 |
| Internal Diamensions | 4096 x 2176 x 2100 mm |
| External Diamensions | 4200 x 2280 x 2900 mm |
| Own Weight | 950 kg |
| Total Weight | 1300 kg |
| Capacity | 6 people (or 8 people with no toilet) |
| Facilities | Toilet with waste disposal, hand basin, mirror Fridge, coffee machine, notice board Fixed table 1800 x 690 mm, 6 chairs Windows: 1 1245 x 825 mm with shutter 2 towel holders, 6 coat hooks Attachable steps, free standing steps 2 radiators 15 L water heater LED light strip Electrical circuit panel |
