Universal Trailer 2700 U5 -2,700Kg – 5.20 x 2.10m


Tandem tilt box trailer with tailgate ramp. 5m long box and 1,820kg payload capacity, perfect for transporting lawn mowers and other drive-on equipment. Galvanised steel chassis for durability and longevity. Wheels mounted underneath allowing all sides to be openable and removable for easy loading & unloading. Dual axles with mechanical overrun brakes.


Additional information



Product Code

2700 U5


Auto-Transporters, Commercial Box Trailers, Tipper Trailers, Universal Series

Internal Dimensions (LxWxH)

520x210x30 cm

Total Dimensions (LxWxH)


Tare Weight

880 kg

Total Weight (ATM)

2,700 kg

Payload Capacity

1,820 kg

Loading Height

63 cm


13", 5 Studs, 4 Wheels


2 Axles, With Brakes

Opening / Detachable Sides

All 4 Sides

Side Material


Floor Material

Phenolic Plywood 18mm

Interior Tie Down Anchor Points

8 Hooks

Other Included Features

13 or 7 Pin Plug, Gas Struts On Back Ramp, Jockey Wheel, Removable Corner Posts, Strong Tailgate Ramp 90cm

Tip Type

Hydraulic Tip

Back Tip Angle

11 degrees

Optional Extras

Aluminium Floor Material, Cage Grill Sides 60cm, Electric Tip including Battery & Charger, Electric Winch With Wire, Extra Height Opening Steel Sides 30cm, LED Lights Kit with Control Box, Ramp Stiffener, Removable Winch Braket, Winch With Wire, Wireless Remote Control for Electric Winch

Rough Size In Feet



For Specs, see the “Trailer Information” section above, or the Variant Trailers website.

Contact us to buy now!

Optional Extras Available With This Model:

Extra alusides open up. 30 cm $ 2,937
High tarp with inside framing 205 cm $ 3,520
Cage 60cm $ 2,695
Aluminium Floor $ 1,947
Eltip incl. battery and charger $ 1,958
Rampeafstivn. (drive u / page.) $ 275
Removable winch $ 264
winch with wire $ 496
Electric winch with wire $ 1,869
Wireless remote control of electric Winch $ 686
LED light kit incl. control box $ 1,319
